Wiska 10112337 BRACE M20 PA Polyamide Straight BraceFITTING with Locknut – IP68, White (Pack of 10)
Product Overview
The Wiska 10112337 BRACE® M20 PA Polyamide Straight BraceFITTING is a high-quality, reliable conduit fitting designed for fast and secure installations. Featuring an innovative large-area integrated TPU seal, it eliminates the need for special cutting tools or additional sealing steps. The captive, visible seal ensures easy inspection, while the 360° hinged closure provides consistent strain relief and robust performance.
Manufactured from flame-retardant polyamide (UL94-V0), this fitting offers superior resistance to heat, impact, and wear. Rated IP68 and IP66, it provides complete protection against dust and water ingress, making it ideal for use in harsh or demanding environments. It is also EN 45545 certified for railway applications and includes a locknut for a secure and watertight installation.
Key Features
- Material (conduit & thread): Polyamide UL94-V0 – durable and flame-retardant
- Seal material: TPU – integrated, captive, and visible for easy inspection
- Protection class: IP68 / IP66 – waterproof and dustproof
- Temperature range: -40°C to +100°C
- Operational area: EN 45545 compliant – suitable for railway applications
- Thread type: M-thread with 1.5mm lead
- NW size: 17
- Ø Connection thread (D): 20mm
- Thread length (L): 12mm
- Closure diameter (VD): 33.2mm
- Internal diameter: 14.8mm
- Key width (SW): 27mm
- Total length (TL): 41.5mm
- Type: Straight conduit fitting
- Includes: Locknut (IP68-rated)
- UL certification: UL 1696 approved
- Colour: White (RAL 9001)
- Model: EBFP-17-20-WH
- Pack size: 10 pieces
Applications
Ideal for use in:
- Industrial and automation systems
- Railway and transport applications
- Marine and outdoor electrical installations
- Control panels and equipment enclosures
